Making A Possible T1 Wiring Diagram With A Biscuit, Cross And Straight

Asked By Francine Piper 10 points N/A Posted on - 07/03/2019

Can anyone tell me how to the t1 wiring from to a biscuit and then to a four-wire channel, using the regular RJ45 connector?

• Status: Open
• Question Views: 78
• Answer Count: 1
• Vote Up 0 Vote Down

• Answer Accepted: No
• Question Category: CYGWIN
• Question Tags: T1 wiring diagram

Answered By Brent K Gamez 0 points N/A #319283

Making A Possible T1 Wiring Diagram With A Biscuit, Cross And Straight

The wiring can be simply done using the diagram. There are two ways you can do the connections. First is the crossover and second way is a single direct connection.
Now, points to remember are –

1. There are eight wires, and we are not using the wires at 3678 places.

2. We will use 1245 for the transmission where 1 is Receiver ring, 2 is receiver tip.

3. 4 is transmitter ring, and 5 is transmitter tip.

4. When receiver, is connected to the transmitter of the biscuit, then it is called a crossover connection.

5. When the receiver is connected to the receiver, then it is called a simple connection.

6. In a crossover connect 12 to 45 and in simple connect 12 to 12.

7. It can be more clearly seen in the diagram.
